MS-1500 Series Product Catalog
Browse all standard output voltage versions of the MS-1500 series.
MS SERIES
鸿博 MS-1500 Series 1500W DC Power Supply Catalog
Supported Control Functions
- Single-Voltage Input: 110VAC or 220VAC single-voltage input design.
- High Efficiency: Efficiency up to 90%.
- Built-in DC Fan: Forced-air cooling for reliable continuous operation.
- Output Adjustable: Output voltage and current are linearly adjustable.
You will be redirected to our official online store www.hongpoepower.com to complete your order and secure payment.
SPECIFICATIONS
MS-1500 Series Key Specifications
| Model | MS-1500 |
|---|---|
| Rated Power | 1500W |
| AC Input | 110VAC or 220VAC (single-voltage) |
| Output Voltage | 12V–200VDC |
| Output Current | 7.5A–100A |
| Efficiency | 87%–90% |
| Voltage Adjustment | 0–100% |
| Current Adjustment | 10–100% |
| Protection | SCP · OLP · OVP · OTP |
| Cooling | Built-in DC fan |
| Dimensions | 240 × 130 × 55 mm |
| Weight | ≈1.8 kg |
| Operating Temperature | -15°C to 65°C |
| Compliance | CE, KC, EAC, RoHS, LVD, FCC, UKCA, DOE |
Main Applications
Industrial Automation
PLCs, robotics, CNC equipment, motors, and industrial control systems.
Test & Measurement
Engineering testing, laboratory equipment, and system verification.
LED & Display
LED modules, advertising displays, and high-power LED equipment.
Need a MS-1500 Adjustable DC Power Supply?
Tell us your required input voltage, output voltage, current and control method.
REQUEST A QUOTE →
